6000mm infeed capacity
3000mm Outfeed table
12"Touch screen graphic display
Power 1000 controller
Remote programming of cutting list via colour graphic touch screen controller - connection via USB key.
5 optimising criteria - longest size, minimum waste, priority size, by volume or by value.
Cutting list entered via controller key pad
Graphic description of the workpiece.
Rack & pinion drive system for pusher with magnetic reading strip to give a high level of repeat cutting accuracy
600mm diameter blade
Cutting capacity - straight - 160mm high by 310mm wide or 80mm by 390mm
Cutting capacity - 45 deg - 160mm x 220mm, 80mm x 270mm
Cutting capacity - 70 deg - 160mm x 100mm, 80mm x 130mm
Angle setting -70 degrees, 0 degrees, + 70 degrees
Adjustable saw stroke speed
Dust extraction 3 off 100mm, 1 off 120mm.
Plexiglass hood with gas springs
Year - 2014 CE
