Comec FMOV Automatic Multi Head Drill For Timber Components

A multi-head vertical and horizontal boring machine that can be specified to suit customers individual production requirements.

  • Multi spindle drilling
  • High Production
  • Various configurations

About this Product

A Heavy duty Vertical and Horizontal Boring machine that can be specified to suit customers individual production requirements. The machine can be equipped with any combination of electro / pneumatic drills spindles and gearboxes as required. Siko readouts are fitted for drill head positions, and on request a digital positioning system can be fitted. Another option is a fully automatic hopper feed loading and discharge system along with double ended cut off saws to cut the component to length. The FM/OV is ideal for quick and precise volume drilling of many types of timber component used in the manufacture of items such as beds, frames and general furniture. On request the machine can be equipped with 2 x sawblades fitted to each shoulder for cutting the material to length at 90 degrees or also cutting an angle up to 45 degrees (FIMO version).

Comec FMOV Automatic Multi Head Drill For Timber Components
Comec FMOV Automatic Multi Head Drill For Timber Components
Specification

Machine can be fitted with any combination of the following:

  • End horizontal heads.
  • Rear horizontal heads.
  • Top vertical heads.
  • Single or multi spindle drill gearboxes.
  • All heads 3hp motor each
  • All main movements via precision linear slides and bearings
  • Adjustable workpiece benches with pneumatic clamps
  • Pneumatic end reference stop
  • Sequencing of the drill heads / automatic loader (when fitted) via PLC control
  • Standard maximum working length 2500mm
  • Siko digital readouts for drill head positioning
  • CE safety norms
  • Approx production output 350 to 400 raills per hour manual loading
  • Approx production output 800 to 840 rails per hour
Options
