A substantially built band resaw that incorporates a special feeding system that allows for an extremely high quality of cut (not usually possible on standard resaws) coupled with the facility to make very thin cuts down to approx. 3mm.
In addition, as the machine is able to use a very think kerf blade it is possible to feed the timber at increased feed rates. Standard features include a 20hp main motor, hydraulic sawblade tensioning, RTT feeding system and pneumatic wheel braking.
Band resaw that incorporates a special feeding system that allows for an extremely high quality of cut coupled with the facility to make very thin cuts down to approx. 3mm.
Thin cutting
Quality saw line
Variable feeding system
A substantially built band resaw that incorporates a special feeding system that allows for an extremely high quality of cut (not usually possible on standard resaws) coupled with the facility to make very thin cuts down to approx. 3mm.
In addition, as the machine is able to use a very think kerf blade it is possible to feed the timber at increased feed rates. Standard features include a 20hp main motor, hydraulic sawblade tensioning, RTT feeding system and pneumatic wheel braking.
Dia of saw pulleys 800mm.
Max. cutting height 400mm.
Max. cutting width 780mm.
Working table 1240 x 800mm.
Max. blade width 54mm x 0.9mm.
Max. / Min. blade length 5530 / 5380mm.
Main HP motor 20.
Automatic star delta starting.
Pneumatic wheel braking.
Front infeed rollers with emergency trip wire.
Front / rear emergency push buttons.
Safety miro-switches on access doors.
Sawblade tension indicator - manual hydraulic tensioning.
Top and bottom sawguides.
Cleaning scrapers on pulleys with sawblade cleaning and cooling felt.
1 x steel sawblade ready for use.
Complete with:
RTT feeding unit - motorised feeding 'carpet' 300mm in height.
Idle feed rollers 160mm x 6 off.
Max fence to blade clearance 220mm.
Feed motor power 0.5hp
Feed speed variable 0-30 mt/min.
