H&M HM-D - Automatic Upstroke Crosscut Saw

Heavy duty automatic push fed upstroke crosscut saw for specialist applications.

About this Product

Designed for versatility, this automatic upstroke crosscut saw is ideal for cutting both single piece and packs of timber with ease. Featuring a robust rack and pinion positioning system, the HM-D ensures accurate positioning of both long and short lengths of timber, guaranteeing precise cuts ever time. Constructed with heavy-duty materials, this machine is capable of handling heavy weights without compromising on performance.

The saw blade action, in a quarter-circle motion, enables the efficient crosscutting of wide sections of timber. Plus, the HM-D can be customised to work in either left-to-right or right-to-left configurations, providing flexibility to suit your workflow. Equipped with a powerful 550mm blade and 7.5hp motor, this upstroke crosscut saw delivers exceptional cutting performance, while the inclined 6m capacity infeed table, angled at 10 degrees, keeps boards securely against the fence for precise cuts.

Safety is paramount, which is why the HM-D comes fully guarded and interlocked, ensuring operator protection at all times. With an outfeed table for added convenience, this crosscut saw is the perfect solution to optimise your timber cutting processes.

  • Designed for versatility
  • Flexible configuration to suit your workflow
  • Capable of handling heavy materials

Specification

Saw Unit

Upstroke crosscut saw

7.5hp braked motor

Pneumatic saw movement

550mm blade

Fully guarded and interlocked

Infeed & Outfeed

6m infeed capacity roller table

50mm diameter rollers 500mm wide to 200mm centres

Rack and pinion drive system

100kg load bearing capacity per roller

Infeed table inclined 10° to keep boards against the fence

60m/min maximum feed speed

Lifting pusher on return stroke

Outfeed table

Connectivity

2 x 100mm dust extraction outlets

AC drive with heavy duty gear box
